Searching For A Bay Window Double Curtain Rail - That Won't Break The Bank!

Introduction to Ordering Bay Window Curtain Tracks

Hi, I'm Lee Stevens from Ezecurtains.co.uk, and it's so easy to order a bay window curtain track to fit your window perfectly on this website. So what you need to do is you need to just get the total width of your bay. So if your track's within the bay only, you just measure around all the sides within the bay.

Measuring Your Bay Window

Enter that total figure into the box. If it's returning out of the bay, then start your measuring from out of the bay, within the bay, and out the other side. Enter that in the box. The next step is how is it going to fix?

Choosing the Fixing Method

To the ceiling, to the wall, combination of both? Click the one that you think that suits your bay window and how you think your track's gonna fit. The third one is a dropdown menu for your bay shape. Now, click on the items on there.

Selecting Your Bay Shape

It'll open a little image to show you the bay shape. If it doesn't look like your bay shape, then click on another one until you find the one that you think looks closest to your bay shape. Then there are a few other items underneath that you'll click on. Finally, at the bottom of the form, you'll enter your personal details and you'll make payment.

Finalizing Your Order Details

You'll receive an email, which will then have a link in it taking you through to the final measuring page. This is the second part of the process, and this is where you'll give us all the exact angles and sizes for each side of the bay. We can work out how to make your track to fit perfectly. So that's it.

Customer Support and Assistance

Have any questions as you move along through the process? Then please just get in touch and ask us, and we'll help you through.

Importance of Accurate Photos for Curtain Orders

Hi, I'm Lee Stevens from Ezecurtains.co.uk and I want to talk to you about photos, photos that you'll send to me through the contact form when you're making an inquiry, or photos that you attach to an order like a bay window curtain track order. Now, we need to see a full shot of the bay. So we need you to stand on the far side of the room so you can get the top of the window in where the track's going to fit, also, the full windows ill around the bay, and out each side of the bay if the curtains are returning outside of the bay.

Tips for Capturing Essential Window Details

Then you may want to take a second shot of the windowsill. If you've got curtains hanging like here, pull 'them to one side, take a shot of the window sill, especially on the end because that's often critical to how the bay track is going to fit. And also how your curtains are going to hang. So below this video you will see some dos and don'ts of the right ways to do your photos.

Conclusion and Additional Resources

So, please have a look, and hopefully this has helped you. And thanks very much for watching.

Hi. I'm Lee Stevens from ezecurtains.co.uk

Understanding Returns in Curtain Tracks

And I want to talk returns to you. We talk on this website about bay returns and we talk about curtain track returns.

Defining a Return

Now, a return is like up here.

Now this, the track comes out of the bay and returns onto the wall into the room. Now, that's a return. Now, if you've got a bay that may be a five-sided bay and you've got a bit of wall here on the side, that is not a return. That's just an internal bend. It only returns if it comes out onto the wall here.

Sizing Your Returns

Now returns can be pretty much any size you want them to be except there needs to be a minimum of fifteen centimeters. So we've got a flat track here that is on a wall-fixed bracket it can clip comfortably back into the bracket. If it's curved, then the bracket won't connect into the back of the track. Now, some people want their return to fill the entire space on the wall, on the side of the base. That's absolutely fine. So you can have a big return, but typically you'll have a return around about twenty centimeters coming out of the corner of the bay across to the side here.

Conclusion and Ordering Guidance

So I hope that's useful, and now you know what we need and what we call a return. When you're ordering, you'll understand what we're talking about.

Introduction to Curtain Tracks

Hi. I'm Lee Stevens from ezecurtains.co.uk

Understanding Curtain Track Brakes

And if you're ordering our regular curtain track that's either for a bay window or a straight window, you may want to add brakes to your curtain track. So what are brakes and what do they do? So let's go and have a quick look.

The Importance of Leveling in Installation

If you fitted a track to a ceiling in a bay or a ceiling over a window, it's more prevalent on ceiling fixed tracks where the track to the ceiling may the ceiling may not be perfectly level. And what happens is gravity has an effect. So you take your curtains, you've then opened them up like so, but because of a slight slope on the ceiling, the curtain wants to start creeping back down the track again. So this is where the brake comes in. So let's have a look at what a brake is, and how you fit it to your track.

Preparing for Brake Installation

I've unhooked the first couple of hooks, and put the curtain back to one side. We've got our curtain drawer rod hanging here and we add these to pretty much all the orders that we supply and fit ourselves and they're great for opening and closing your curtains and these fit on the second glider in.

Fitting the Brake on the Glider

Now, on the first glider, this is where we're going to fit our little break over the top of that glider.

Close-Up on Brake Mechanism

And a little close-up, it's hard to see, but it's like a little four legged spider or little table with no top on it. So let's move in really close and have a look at how we clip this over the first glider.

Aligning the Brake for Proper Fit

Just before we fit this little break on, you'll find that the four legs on it, that they're narrower on one side and wider on the other side. We want the wider ones to be fit into each side and the narrow ones front to back. Now, this little break, the little legs on the back of the break fit into the channel. Give it a squeeze.

Securing the Brake in Place

I know it's very difficult to see because my thumb's in the way, but the front legs are going to fit into the front of the track. So we're gonna squeeze it, and the front legs have gone into the front of the channel, and the back legs have gone into the back of the channel. And that provides the friction that we need on this track. So, we'll have a look at now how it affects the free flowing of the curtains.

Testing the Brake Functionality

So let's push the curtain back now, and that break holds the curtain in place. It's only a little bit of friction on the track, but it's enough that if you've got a slope on your track ever so slight, you're not going to find that creep back across your window and effectively where you leave the curtain is where it's going to stay.

Conclusion and Ordering Information

Back again, and there we go. So it's as simple as that, and I hope you found that useful. You can order these either with your track or you can order them afterwards.

Your choice.

Assembling the Curtain Tracks

Hi. If you order one of our hand draw slimline curtain tracks and it's wide enough that it needs to come in two pieces with the center joiner, this is what's going to happen. You're going to have the two tracks and on one track, you're going to have the center joining piece, and the inside grub screw needs turning anti clockwise one turn to loosen it so that you can actually slide it off the end of the track like so.

Securing the Tracks Together

And then we can slide the other side of the track in to meet in the middle and then tighten up all four of the grub screws clockwise a couple of turns and that locks the two pieces together solidly ready for fitting your track.

Introduction to Curtain Installation

Hi. I'm Lee Stevens from ezecurtains.co.uk

And I get lots and lots of people telling me my ceiling isn't strong enough to support a ceiling fixed curtain track. I need to know where the joists are so I can fix all my brackets into the joists. Your ceiling almost undoubtedly is going to be strong enough because I've fitted thousands of these Baytrax over the thirty years almost.

And also, the joists are never going to be in the right place to fit all your brackets.

If you watch my other fitting videos, you'll see how I approach this. You don't need to know where all the joists are because they're not going to be in the right place. So you can hear that's hollow. All ceilings are hollow or almost all ceilings, unless you've got a concrete ceiling, but almost nobody does in a domestic dwelling. So if you're hanging domestic sized curtains, even big ones, blackout, floor length, really wide, as long as they're not like four meters long and six meters wide, and you truly are super heavy stage curtains, but this website is not about those kind of curtains and those kind of tracks. It's about domestic sized curtains, domestic sized windows.

Fitting the Curtain Track

So you're going to present your track to the ceiling. You're going to screw all the screws in. If you have bad fittings, then you use the plugs that we supply. The plugs we supply with the screws will suit ninety five, ninety eight percent of the fittings that you need to do and give you a firm enough fixing.

You're almost certainly when you're doing all the brackets up into the ceiling and just driving the screws in, you're going to hit some timber in the ceiling. Fantastic. You only need to worry about the ones where you don't. The ones where you don't, then if our plugs are still not giving you a firm no fixing, which is highly unlikely, then there's a couple of other fittings here that we use.

Alternative Fittings and Tools

And you can find the links to these in this video. And also, if you're watching it in the right place, you'll see the links below the video.

Now use these. We only use these if our regular fittings fail, and that's almost never.

But it's handy to know where they are, where you can get them from. I get both of these from Screwfix. Nice and cheap. So start with the basics and then move on to these if you have to. Now at the end of the track, on each end, just within the ceiling, just within the bay, there's going to be a beam across the top of the ceiling.

Dealing with Metal Lintels

Now, almost certainly, in most houses now, you're going to find it's a metal lintel. If it's timber, fantastic. You just drive the screw in, you've got a good grip. If it's metal, you're going to need to use the drill bit that you can find in the link in this video that takes you to Screwfix.

And it's a three and a half mil high speed drill bit, and it will cut pilot hole into the lintel. You'll be able to use the screws we supply to then drive directly into that hole without using your plug. That will grip. If you've got a track that returns out to the bay on each side, almost certainly, it's going to be going into brickwork.

Fixing to Brickwork

So use the plug supplied, six mil masonry drill bit, drill the hole, fix your wall fixed bracket on the return.

So that's fundamentally it. Don't worry. You don't have to go upstairs and pull the floorboards up. You don't need to start looking, you know, where every individual joist is because they're not going to be in the right place to support your track.

Final Installation Tips

You're going to be moving your brackets to where the joist is, but it's not going to give your track the support to suspend your curtains from this track. So forget about that. Just follow the guide the fitting guide, and they will show you how to fit our tracks. And then also just use the links in this video to get the bits that you may need.

You don't have to buy all these straight away. Just nip out your local branch if you need them. But almost certainly, you're not going to need them other than these three and a half mil drill bits for piloting the lintel across the top. So your last bracket on each side before your track turns out to the bay.

If it's not turning out to the bay, then the end of the track here is going to be nice and secure to hang your curtains because it's going to be fixed into that metal lintel. And if it's a wooden lintel in a really old house, then fantastic. Don't need to do any drilling. You just screw the screws directly in and you got a super solid fixing.

Conclusion and Support

So I hope that helps. And if you have questions as you move along ordering, fitting, then just get in touch.

Introduction to Bay Window Ceilings

Hi. I'm Lee Stevens from ezecurtains.co.uk

And I want to talk to you about battens on bay window ceilings.

Debunking the Need for Wooden Battens

People talk to me all the time about, do I need to fix wooden battens to the ceiling in my bay? And the answer is absolutely not. They just look plain ugly, and they do not achieve anything. You might as well fix your track directly to the ceiling. Our tracks are designed to be well fitted to ceilings in bay windows.

Alternative Fixings for Plasterboard Ceilings

You're going to find that mostly you're into plasterboard in ceilings, which is fine with the plugs that we supply. Now if you had a spot that our plugs are not doing the job, then there's alternate fixings. And there's a video that you can see a link to here that shows you what those alternative fixings are and how to use them.

Fixing Techniques at the Bay's End

When it comes to the end of the bay, and just before you leave the bay on each side, assuming you're gonna return out onto the walls, you're gonna be fixing into the lintel over the top of the window.

Again, the fitting videos discuss that in more detail.

Final Recommendations on Installation

When you return out to the bay, if you're going to return out onto the walls on each side of the bay, you're gonna be fixing almost certainly into brickwork. So they'll be nice and solid fixings. So when it comes to the wooden battens, don't use them. Fit directly to the ceiling. Our tracks are designed to fit flush to the ceiling, and they're really sturdy, solid, and you won't need to use wooden battens. So I hope that was useful.

Introduction to Ceiling Fitting

Hi, I'm Lee Stevens from Ezecurtains.co.uk

And I want to show you what to do if you're fitting a track to the ceiling in a bay or a ceiling in a room, and you're struggling to get a good fixing.

Alternative Fixing Method Explained

Here's an alternative fixing that you can use. So let's go and have a quick look. Okay. The fixing we're going to use is a toggle bolt. We've got a screw head on this end and then we've got two little wings that are spring loaded on this side, and they'll pop open once we go through the hole that we're going to drill into the ceiling with an eight mil drill bit. So let's go and have a look at that.

Preparing the Ceiling for Installation

Creating an eight millimeter hole in the plasterboard ceiling ready to fit the, toggle bolt.

Installing the Toggle Bolt

Okay. We've got the, regular track here with the bracket on ceiling fix. And we've got the toggle, with the wings on the top here now. And we've got this screw head inside the bracket. So we're going to present this up to the ceiling now and pop it into that hole we've just created.

So let's go and have a look at that.

Okay. I've got the wings on the toggle folded backwards, and we're popping it up now. And I could hear the wings pop open. And if we pull this down now, the wings are holding it up in there. So we're going to just use a driver now to tighten up this. And you need to pull down on the track and the bracket.

Securing the Track to the Ceiling

And there we go. That toggle bolt has now firmly fitted that track up to the ceiling.

Do that for any brackets that you're not happy that are completely solid up to the ceiling.

Final Thoughts on Installation Techniques

Okay. So we got that track now, and I'm really pulling down from the ceiling, and that is a solid fixing. It would take an enormous amount to break that to fixing free. So only use these if the red plugs we supply are not doing the job well enough, then get a packet of these from Screwfix. You can find the link in the video just here, to the ones that I use, and, you'll have no problems at all fitting your track to a ceiling in a bay or just over the top of the window on a straight window. So I hope that was useful.

Introduction to Ezecurtains

Hi. I'm Lee Stevens from ezecurtains.co.uk

Overview of Wall Bracket Options

And I want to talk to you about the wall brackets that we offer with our regular track. That's regular bay track, regular wall fix track, the brackets that you're going to use for any wall fix that you do. We've got four options. We've got the three centimeter wall bracket, four centimeter wall bracket, six and a half centimeter wall bracket, and nine centimeter wall bracket.

Understanding Bracket Projections

That's the projection off the wall to the front edge of the track once it's fitted on the bracket. So that's the distance it'll push off the wall. So let's have a look at the two different styles that we've got of these four brackets. So if you want to move in, we'll have a quick look at those.

Installation of Clip-In Brackets

Keep it running. So with the three and four centimeter clip in brackets, once your bracket is screwed to the wall through the hole in the bottom here, you present your track to the front of the bracket and you tap it.

And it locks. That click is locking it in place now. Now it locks solid. If you find you need to release it, underneath is a little lever. Push it with your thumb, twist the track, and it pops off.

Lever Lock Bracket Mechanism

Now when it comes to the six and a half and the nine centimeter bracket, we have what we call a lever lock bracket.

And there's a little lever here with a cam on the front and that slots into the bottom. But prior to putting the cam into the bracket on the front, we keep that out because it gives you access to fix the bracket here.

Important Installation Tips

And with these brackets, we supply a little washer with the screw so that you need to have the washer on before you put the screw in here because if you don't, it then when you tighten it up, forces that slot to open up and potentially damage the bracket. So washer on the screw, fix the bracket.

Finalising the Bracket Installation

Once the bracket's fixed in place, you push these little cams in, hear a click, and then we've got the lever in position here now. So that needs to be pointing downwards six o'clock.

The track goes to the front like so, and then you turn the lever either left or right, and that bracket is now locked solidly in place.

To unlock it, push the lever back to six o'clock at the bottom, and the track comes off. And that's all there is to it.

Summary of Bracket Types

So there you have it.

Two brackets that are "clip in", three and four centimeter projection brackets, then two brackets which are "lever lock", six and a half centimeter and nine centimeter projection brackets.

Conclusion on Wall Fix Brackets

So that's all your options for the regular track on wall fix brackets.

Introduction to Slimline Curtain Tracks

Hi. Welcome to Ezeurtains. And I want to chat with you about our slimline curtain tracks. Bay windows, straight, we can bend them to fit pretty much any bay window shape.

Benefits of Slimline Tracks

And there are two reasons why you choose the slimline track. One is you just like the look of the slimmer profile. And two, sometimes there are practical reasons such as inward opening windows or you may have shutters on your windows, and the shutter doors need to open underneath the track. It's a really smooth working track and will hold pretty much any size domestic weight curtains, wide, long, blackout, doesn't really matter. So let's have a look at how well they move across this track.

Demonstration of Curtain Movement

So there you go, really smooth working curtains. So any size like I said before, and they will glide like a dream.

Overview of Track and Bracket Options

Let's have a look at the track itself and the bracket options that go with this track. So we've got the, track here and it's a real sturdy track and you can barely put any twist on it. And once this is fitted to the brackets, wall or ceiling fix, it there's almost no flex in it at all.

Detailed Bracket Specifications

Now the brackets, we've got three wall brackets here. We got the four and a half centimeter, seven and a half centimeter, and the ten centimeter brackets so you can project further off the wall should you need to. And then finally, we've got the TopFix bracket here that's a really neat slim bracket and this has a little cover that covers it so that once it's fitted you don't see the screw fixings.

Purchasing Information

So if you decide you would like to buy one of these tracks, you can get a price to fit your window perfectly on the calculator at the bottom of this page.

Enhancing Aesthetic Appeal of Brackets

Okay. So we've got the track fitted up to the ceiling now and we want to make those brackets look a little bit more attractive. So we have a cover here that we can slide on like so, and then just simply push on a locking position, and it just makes everything look so super neat, so that's it.
